AppShark

Appshark is a static taint analysis platform to scan vulnerabilities in an Android app.

Prerequisites

Appshark requires a specific version of JDK -- JDK 11. After testing, it does not work on other LTS versions, JDK 8 and JDK 16, due to the dependency compatibility issue.

Building/Compiling AppShark

We assume that you are working in the root directory of the project repo. You can build the whole project with the gradle tool.

$ ./gradlew build  -x test

After executing the above command, you will see an artifact file AppShark-0.1.2-all.jar in the directory build/libs.

Running AppShark

Like the previous step, we assume that you are still in the root folder of the project. You can run the tool with

$ java -jar build/libs/AppShark-0.1.2-all.jar  config/config.json5

The config.json5 has the following configuration contents.

{
  "apkPath": "/Users/apks/app1.apk"
}

Each JSON has these basic field.

apkPath: the path of the apk file to analyze
out: the path of the output directory
rules: specifies the rules, split by ,. Default is all *.json files in the $rulePath directory
rulePath: specifies the rule's parent directory, default is ./config/rules
maxPointerAnalyzeTime: the timeout duration in seconds set for the analysis started from an entry point
debugRule: specify the rule name that enables logging for debugging

For more config field, please visit net.bytedance.security.app.ArgumentConfig

If you provide a configuration JSON file which sets the output path as out in the project root directory, you will find the result file out/results.json after running the analysis.

Interpreting the Results

Below is an example of the results.json.

{
  "AppInfo": {
    "AppName": "test",
    "PackageName": "net.bytedance.security.app",
    "min_sdk": 17,
    "target_sdk": 28,
    "versionCode": 1000,
    "versionName": "1.0.0"
  },
  "SecurityInfo": {
    "FileRisk": {
      "unZipSlip": {
        "category": "FileRisk",
        "detail": "",
        "model": "2",
        "name": "unZipSlip",
        "possibility": "4",
        "vulners": [
          {
            "details": {
              "position": "<net.bytedance.security.app.pathfinder.testdata.ZipSlip: void UnZipFolderFix1(java.lang.String,java.lang.String)>",
              "Sink": "<net.bytedance.security.app.pathfinder.testdata.ZipSlip: void UnZipFolderFix1(java.lang.String,java.lang.String)>->$r31",
              "entryMethod": "<net.bytedance.security.app.pathfinder.testdata.ZipSlip: void f()>",
              "Source": "<net.bytedance.security.app.pathfinder.testdata.ZipSlip: void UnZipFolderFix1(java.lang.String,java.lang.String)>->$r3",
              "url": "/Volumes/dev/zijie/appshark-opensource/out/vuln/1-unZipSlip.html",
              "target": [
                "<net.bytedance.security.app.pathfinder.testdata.ZipSlip: void UnZipFolderFix1(java.lang.String,java.lang.String)>->$r3",
                "pf{obj{<net.bytedance.security.app.pathfinder.testdata.ZipSlip: void UnZipFolderFix1(java.lang.String,java.lang.String)>:35=>java.lang.StringBuilder}(unknown)->@data}",
                "<net.bytedance.security.app.pathfinder.testdata.ZipSlip: void UnZipFolderFix1(java.lang.String,java.lang.String)>->$r11",
                "<net.bytedance.security.app.pathfinder.testdata.ZipSlip: void UnZipFolderFix1(java.lang.String,java.lang.String)>->$r31"
              ]
            },
            "hash": "ec57a2a3190677ffe78a0c8aaf58ba5aee4d2247",
            "possibility": "4"
          },
          {
            "details": {
              "position": "<net.bytedance.security.app.pathfinder.testdata.ZipSlip: void UnZipFolder(java.lang.String,java.lang.String)>",
              "Sink": "<net.bytedance.security.app.pathfinder.testdata.ZipSlip: void UnZipFolder(java.lang.String,java.lang.String)>->$r34",
              "entryMethod": "<net.bytedance.security.app.pathfinder.testdata.ZipSlip: void f()>",
              "Source": "<net.bytedance.security.app.pathfinder.testdata.ZipSlip: void UnZipFolder(java.lang.String,java.lang.String)>->$r3",
              "url": "/Volumes/dev/zijie/appshark-opensource/out/vuln/2-unZipSlip.html",
              "target": [
                "<net.bytedance.security.app.pathfinder.testdata.ZipSlip: void UnZipFolder(java.lang.String,java.lang.String)>->$r3",
                "pf{obj{<net.bytedance.security.app.pathfinder.testdata.ZipSlip: void UnZipFolder(java.lang.String,java.lang.String)>:33=>java.lang.StringBuilder}(unknown)->@data}",
                "<net.bytedance.security.app.pathfinder.testdata.ZipSlip: void UnZipFolder(java.lang.String,java.lang.String)>->$r14",
                "<net.bytedance.security.app.pathfinder.testdata.ZipSlip: void UnZipFolder(java.lang.String,java.lang.String)>->$r34"
              ]
            },
            "hash": "26c6d6ee704c59949cfef78350a1d9aef04c29ad",
            "possibility": "4"
          }
        ],
        "wiki": "",
        "deobfApk": "/Volumes/dev/zijie/appshark-opensource/app.apk"
      }
    }
  },
  "DeepLinkInfo": {
  },
  "HTTP_API": [
  ],
  "JsBridgeInfo": [
  ],
  "BasicInfo": {
    "ComponentsInfo": {
    },
    "JSNativeInterface": [
    ]
  },
  "UsePermissions": [
  ],
  "DefinePermissions": {
  },
  "Profile": "/Volumes/dev/zijie/appshark-opensource/out/vuln/3-profiler.json"
}

License

AppShark is licensed under the APACHE LICENSE, VERSION 2.0

Security Notice

UI/Server is an auxiliary testing tool that should not be used in production environments and can only be deployed for local testing.
